Gallery›Wellcome Collection›Engineering: diagrams of loading for simple and composite wooden beams. Engraving by J. Davis after R. Tredgold, 1820.
Engineering: diagrams of loading for simple and composite wooden beams. Engraving by J. Davis after R. Tredgold, 1820.
Wellcome Collection

Engineering: diagrams of loading for simple and composite wooden beams. Engraving by J. Davis after R. Tredgold, 1820.

R. Tredgold · 1820

CC0 — Public Domain
Wellcome Collection

Lettering: Pressure of beams and centre of gravity. ; Drawn by R. Tredgold. ; Engraved by James Davis.

🔒
